DPU3000-W8

Products

Wireless Access Controller

Model: DPU3000-W8
Service Status: On Sale
Type: Compatible with Secusys2000 management platform
Specification:
· Operating Voltage: 12V DC (±10%)

· Operating Current: ≤200mA

· Working Temperature: -40C~70C

· Dimensions: W138 x H244 x D33mm

· Weight: 0.35Kg
Key word: Access Control, Card & Biometric Reader, proximity, smart card, face recognition, biometric, fingerprint, Security, Wireless lock, Aperio, Kadio

Product Info

DPU3000-W8 is a powerful and advanced 433MHz wireless access controller that compatible with DPU3000NT & POE controllers.

Application

Office, Apartment, Government, etc.

Features

Advanced ARM M4 Processor, high speed response-100,000 credentials in 0.1 sec
Flexile configuration, compatible with DPU3000NT & POE controllers
Installed on ceiling, closed to locks
Supports equipment through built-in 2 pcs RS485 bus
Flexible programmable flow control between inputs and outputs
POE 803.11af, power supply through a single CAT5/6 wiring
Wireless door sensor
Wireless REX Button
On-Line and Off-Line modes:

l On-Line:Connected to the Sphinx software

l Off-Line:Standalone,not connected to server

Specification

· Frequency: 433MHz

· CPU: 32 bits ARM processor

· Auxiliary Input: 4

· Channel: 8

· Communication interface: RS-485/TCPIP

· Cardholder Capacity: 10,000

· Transaction Storage: 200,000

· Maximum LAN Distance: 1200 meters (4000ft) using RS-485.

· Operating Voltage: 12V DC (±10%)

· Operating Current: ≤200mA

· Working Temperature: -40C~70C

· Dimensions: W138 x H244 x D33mm

· Weight: 0.35Kg
